Sensitive Switch NSN: 930-01-135-0148
Switch
| Spec | Detail |
|---|---|
| Hazardous Locations/environmental Protection | Waterproof |
| Overall Length | 1.810 Inches |
| Body Diameter | 0.810 Inches |
| Body Length | 0.380 Inches |
| Actuator Style | Flush Round |
| Actuator Diameter | 0.438 Inches |
| Actuator Height | 0.032 Inches |
| Maximum Voltage Rating In Volts | 28.0 Dc |
| End Item Identification | M60 Tank Family |
| Inclosure Type | Fully Inclosed |
| Mounting Method | Threaded Stud |
| Up Contact Arrangement Nonpile | Single Throw 1 Pole Both Positions Maintained Single Switch Unit |
| Switch Release Force | 226.8 Grams |
| Switch Actuating Force | 453.6 Grams Min. And 907.2 Grams Max. |
| Actuator Movement | 0.015 Pretravel Inches Min. And 0.015 Overtravel Inches Min. And 0.005 Differential Inches Max. |
| Contact Load Current Rating At Maximum Rated Voltage | 15.000 Amperes Resistive Dc And 7.500 Amperes Inductive Dc And 7.500 Amperes Lamp Dc |
| Special Features | Cables 12.000 Lg From Switch |
| Terminal Type and Quantity | 2 Wire Lead |
